There are many types of separator,and different types are suitable for different materials.Different models are also made according to the customer's requirements for material fineness.Common separator include cyclone type cyclone type separator,three-separation separator,centrifugal separator,coal mill type separator,calcium powder type separator,etc.Later,many high-efficiency separator and high-efficiency three-separation separator were developed.They are new generation varieties that improve the original shortcomings and increase production.
Product performance characteristics:
(1)It is a static grading and disintegrating equipment with no moving parts,reliable and stable operation,which is conducive to the smooth operation of the roller press and improves the system output;
(2)The structure is simple and the wear-resistant parts have a long service life;
(3)The air volume is small and the pressure difference loss is small;
(4)The fineness of the finished product can be controlled by adjusting the wind speed,which is convenient and reliable;
(5)It has a drying function.

Cyclone separator
The cyclone separator drives the 60 blades on the turntable to rotate through the speed regulating motor and the secondary reduction to form
The horizontal cyclone separator has a grading effect on the powder.The speed of the blade is adjusted according to the size of the finished powder.When you want to obtain finer powder,increase the blade speed to increase the contact between the blade and the powder,so that the unqualified powder is thrown to the outer wall by the blade and separated from the airflow.The coarse powder falls into the grinding chamber for re-grinding due to the effect of gravity.The qualified finished powder is sucked into the large cyclone collector by the blade along with the airflow.After the airflow and the powder are separated,the powder is collected.
Three-separation separator
Three-separation separator The three-separation separator breaks through the conventional closed-circuit grinding system"coarse and fine powder"two-separation theory,and divides the material into"one into three",namely coarse powder,medium coarse powder and fine powder.The product system configuration is simple and low-cost,which can greatly increase the output of the mill.Its internal structure is reasonable and the powder selection effect is significant.It is a product that improves the product quality of the grinding system after the implementation of the new cement standard.
Centrifugal separator
Centrifugal separator Centrifugal separator is a wind classifier.After the transformation,the centrifugal separator solves the problem of high circulation load of the previous generation of centrifugal separator,which can not only increase the output of the mill and reduce costs,but also improve product quality.
The centrifugal classifier is a classifier for cement industry,invented by the British Munfound and Moadie in 1885.Over the past 100 years,with the advancement of technology and the improvement of production process requirements,it has undergone a series of technical transformations and developed into various structural forms,such as Smnevam type,C'co type,Tso type and Heyd type.The structure and classification principle of these classifiers are similar.Their common feature is that the air flow for classifying is internal circulation,that is,the air classifier,the circulating fan and the cyclone for collecting fine powder are combined together,so it is also called an internal circulation air classifier.The technical transformation of the traditional centrifugal classifier using NHx rotor classifier technology can significantly improve the classifier's powder selection efficiency and the output of the grinding system.This technology is particularly suitable for the transformation of old lines with insufficient technical transformation funds,low mill height,and difficulty in replacing new classifiers.It has certain promotion and application value and market application prospects.
Ceramic aluminum sand separator
The ceramic aluminum sand separator adopts a high-throwing capacity scattering plate to strengthen the scattering and swirl capacity,so that the material particles can be fully dispersed and lifted,and the material classification and dispersion performance is enhanced.The positions of the powder selection area and the lifting area are reasonably adjusted to improve the powder selection efficiency.The classifier spindle can be steplessly regulated.The multi-stage lining protection extends the service life of the main machine.The use of a split-petal detachable cage rotor greatly saves maintenance time and difficulty.The coarse powder pipe and the fine powder pipe use double interlocking air valves,which greatly reduces the air leakage rate and overcomes the shortcomings of large dust during the operation of the previous classifier.
Fly ash separator
The classification principle is improved.It adopts the organic combination of gravity centrifugal and cyclone vortex multiple classification force fields
and has high classification accuracy.The lower cage rotor can help the accumulated material particles to be lifted again,increase the classification capacity,and effectively reduce the fine powder content in the coarse powder.The speed regulating motor is used to adjust the spindle speed,which is convenient to adjust the fineness,high sensitivity,and wide adjustment range.The space range of the powder selection area and the lifting area is optimized to improve the powder selection efficiency.Low-resistance cyclone dust collector effectively reduces the resistance of the flow distribution and improves the dust collection efficiency.A variety of anti-condensation devices such as elastic sweepers are optimized and designed inside the machine,which has a good anti-condensation effect.The dust-proof and vibration-reducing fan without footing is easy to install and saves investment.
Slag powder selector
Slag powder is usually required to reach a higher specific surface area when grinding slag.Generally,the specific surface area of​​slag powder is expected to be above 420m.When ultra-fine grinding slag,the average particle size of the material entering the powder selector is only about 10-12μm,and the particle size is only about 50-60μm.Moreover,the density of slag is less than that of cement.At present,the ordinary powder selectors used in cement raw material and cement clinker grinding systems cannot meet the production requirements of slag grinding systems in terms of material spreading,grading and finished product collection.
